SB6c-22

ROLL-INBUDDY XL

The larger Roll-InBuddy for roll-in showers
Roll-InBuddy XL is designed for mobility impaired individuals requiring a larger seat.
With all the features and benefits of the Roll-InBuddy, the XL model offers comfort and support for users up to 200kg in weight and a seat that’s 560mm wide. The SB6c-22 is designed for function and safety within roll-in showers and wet rooms. A carer can support entry and use of the shower safely thanks to the strong, water-proof aluminium frame (covered by a lifetime warranty).

Roll-InBuddy XL also doubles as a fully-featured toilet chair. With a maximum toilet clearance of 480mm, the chair will fit over most standard home toilets. For users needing support outside the bathroom, Roll-InBuddy XL comes with a complete commode system.

With additional support from foot and armrests, Roll-InBuddy XL is an excellent choice for larger individuals.

Roll-InBuddy XL SB6c-22 at a glance

  • Supports up to 200kg
  • 22” (560mm) wide seat cushion
  • Highly durable, lifetime warranty frame
  • Designed for roll-in showers
  • Complete commode system included

How it Works

Showering

Roll-InBuddy XL is simple and effective:
  • The carer prepares the user for showering and locks the Roll-InBuddy XL’s wheels down.
  • Fold-away arms allow hassle-free transfer onto the chair.
  • Once seated, the footrest can be adjusted for comfort.
  • For extra support, lap and chest safety belts should be worn at all times.
  • Simply take off the brake and transfer the user into the shower.
  • Lock the caster wheels back into place – RollIn-Buddy XL will stay fixed to the shower floor if required.
  • Once shower is complete, simply unlock the wheels and bring the user out.

Toileting

If toilet use is required, the Roll-InBuddy XL can be positioned over most standard toilets. This makes it easy for toilet to shower transfers with no extra lifting required by a home carer.

Features

  • Weight capacity – 200kg
  • Rolls over most standard toilets
  • Low maintenance
  • Arms – removable / lockable / flip-back
  • Height adjustable
  • Footrests – removable and swing-away, height-adjustable
  • No rust aluminium frame (Grade 6061 T6)
  • Stainless steel parts and hardware (Grade 304)
  • Safety belts – lap or chest belts
  • Caster Wheels – 100mm all locking
  • Commode system
  • Tool-free assembly
h

Download Specs

Roll-InBuddy XL SB6c-22 Specification Document

  • Weight capacity – 200kg
  • Rolls over most standard toilets
  • Low maintenance
  • Arms – removable / lockable / flip-back
  • Height adjustable
  • Footrests – removable and swing-away, height-adjustable
  • No rust aluminium frame (Grade 6061 T6)
  • Stainless steel parts and hardware (Grade 304)
  • Safety belts – lap or chest belts
  • Caster Wheels – 100mm all locking
  • Commode system
  • Tool-free assembly
h

Download Specs

Roll-InBuddy XL SB6c-22 Specification Document

Dimensions

Imperial Diagram

Roll-InBuddy XL SB6c-22 Dimensioned Drawings in imperial measurements.

Metric Diagram

Roll-InBuddy XL SB6c-22 Dimensioned Drawings in metric measurements.

  • Chair Width – over caster wheels 587mm
  • Chair Width – over arms 660mm
  • Chair Width – inside arms 560mm
  • Chair Length – including footrest 930mm (650mm with footrests removed)
  • Backrest Width 547mm
  • Backrest Height from Cushion to top 380mm
  • Toilet Height clearance (maximum) 490mm
  • Toilet Width clearance at narrowest 443mm (at casters)
  • Toilet clearance can depend upon the shape of the toilet pan
  • Seat Cushion Dimensions 550mm W x 430mm D
  • Seat Height from Floor 510mm to 585mm (Adjustable)
  • Seat Cushion Opening 175mm W x 335mm L
  • Box Dimensions L 590mm x W 560mm x H 490mm
  • Box Gross Weight 16.5kg

Catalogues & Manuals

h

Product Catalogue

Download your Showerbuddy Product Catalogue showcasing the full Showerbuddy range of chairs and transfer systems.

h

User Manual

The Roll-InBuddy XL SB6c-22 User Manual includes a full parts list as well as assembly, setup and operation instructions.

Roll-InBuddy XL SB6c-22

Accessories

Some of these Accessories are compatible with other ShowerBuddy products.
Visit our Accessories Page for a full list.

Want to learn more?

The Showerbuddy team provides ongoing product support to users, Occupational Therapists and distributors. If you’re interested in this product, please get in touch below:
